The NUX B-7 PRO is a game-changing wireless in-ear monitor system, designed for musicians who demand high-quality audio, ease of use, and total freedom on stage. With interference-free 2.4 GHz transmission, 24-bit / 48 kHz high-resolution sound, and ultra-low latency, the B-7 PRO ensures crystal-clear monitoring without dropouts. Whether youre performing live, rehearsing, or recording, this system provides seamless wireless audio monitoring with an intuitive automatic pairing system.
A key feature of the B-7 PRO is its USB audio interface capability, allowing you to monitor and record audio directly from your computer or mobile device. This makes it ideal for musicians who want to play along with a click-track, backing tracks, or rehearse with recorded mixes. The high-definition color LCD display provides all essential information at a glance, even in dark stage environments, while the adjustable Low Latency Mode and Stable Mode offer flexibility depending on your performance setting.
After your performance, simply place the receiver (belt pack) onto the transmitter, and it will automatically charge on the go using the built-in battery of the transmitter. This means your receiver recharges while traveling to your next gig, ensuring it's ready whenever you are.
Key Features
Premium Stereo Audio Quality 24-bit / 48 kHz resolution for ultra-clear, detailed sound.
USB Audio Interface Connect to a PC, Mac, or smartphone to monitor click-tracks, backing tracks, or DAW playback directly through your in-ears.
Ultra-Low Latency Enjoy near-instantaneous sound transmission with just 7.3 ms latency in Low Latency Mode.
Automatic Charging on the Go After performing, dock the receiver onto the transmitter for convenient recharging while traveling.
Long-Distance Wireless Freedom Operates up to 50 meters (165 feet) without dropouts or interference.
Automatic Pairing System Turn on the TX (transmitter) and RX (receiver) for instant synchronization.
High-Definition Color LCD Display Easily monitor battery status, signal strength, and settings.
Adjustable Transmission Modes Choose between Low Latency Mode for real-time monitoring or Stable Mode for interference-prone environments.
User-Friendly & Versatile Design
Up to 6 Hours Battery Life Built-in Li-ion rechargeable batteries provide long-lasting performance.
Effortless Charging Place the RX on top of the TX to recharge without additional cables.
Custom Boot-Up GIF Personalize your startup screen with a custom animated logo or image.
Interference Management For optimal performance, keep the B-7 PRO RX at a safe distance from the NUX B-8 TX to avoid interference.
Specifications
Operating Frequency Band: 2.4 GHz (2400-2483.5 MHz)
Transmission Mode: Frequency Hopping
RF Output Power: 10mW E.I.R.P. max
Audio Quality: 24-bit / 48 kHz
Frequency Response: 20Hz - 20kHz
Latency: 7.3ms (Low Latency), 10.85ms (Default), 14.33ms (Safe Mode)
Unbalanced Input Impedance: 10kO
Balanced Input Impedance: 20kO
AUX Input Level: 2.1 Vrms (8.7 dBu) max
Balanced Input Level: 9.8 Vrms (22 dBu) max
Headphone Output Impedance: Minimum 13O
Headphone Max Output Power per Channel: 57mW (THD <0.1%, RLOAD = 16O, 1kHz)
Channel Separation: -105dB
THD+N: <0.01% typical
Dynamic Range: 110dB A-weighted
Output Level Adjustment Range: Mute -86dB to +12dB
Auto-Off Function: Turns off after 10 minutes of inactivity or lost connection
Built-in Battery: TX: 3.7V / 3000mAh Li-polymer / RX: 3.7V / 400mAh Li-polymer
Battery Life: Up to 6 hours (TX & RX)
Power Requirement: DC 9V, 1A min, negative tip power supply (Transmitter)
Operating Range: Up to 50m (165 ft)
TX Dimensions: 140mm × 97mm × 53mm (L × W × H)
TX Weight: 525g
RX Dimensions: 47mm × 71mm × 22mm (L × W × H)
RX Weight: 51g
