NUX NSS-4 Pulse IR Loader Pedal for Guitar, Bass, and Acoustic Guitar

Professional cabinet simulations in a compact pedal

The NUX NSS-4 Pulse is a compact IR loader that adds convincing speaker cabinet and instrument sounds to your pedalboard. The pedal features three different modes: EG CAB for electric guitar, BS CAB for bass guitar, and AG IR for acoustic guitar.

Thanks to IR technology, you can connect directly to a mixer, audio interface, or active monitor without using a traditional guitar amplifier. The 1024-sample processing ensures a natural response and detailed reproduction of the chosen impulse response.

Loading your own impulse responses

Via the accompanying software, you can load your own IR files in WAV format. The program automatically converts suitable files, allowing you to easily use your favorite cabinet and acoustic guitar profiles.

The NUX Pulse supports stereo and can be set to true bypass or buffered bypass. This makes the pedal versatile for use at the end of almost any effect chain.

Silent practice and recording via USB

The 3.5mm headphone jack enables silent practice without a separate amplifier. Additionally, the NSS-4 can be used as an audio interface via USB to record directly into a DAW. This makes the pedal suitable for home use, studio recordings, and amplifier-less stage setups.

Key Features

• Compact IR loader pedal
• Suitable for electric guitar, bass, and acoustic guitar
• EG CAB, BS CAB, and AG IR modes
• 1024-sample real-time IR processing
• Supports external IR files in WAV format
• Stereo support
• True bypass or buffered bypass
• Headphone output for silent practice
• USB audio function for direct recording
• Low power consumption

Product specifications

Article number	NSS4
Brand	NUX
Model	NSS-4 Pulse
Type	IR loader pedal
IR modes	Electric guitar cabinet, bass cabinet, and acoustic guitar
IR resolution	1024 samples
DSP processing	48 kHz / 32-bit
AD/DA conversion	48 kHz / 24-bit
Dynamic range	103 dB
Input impedance	1 MΩ
Output impedance	10 kΩ
Bypass	True bypass or buffered bypass
Additional connections	Headphone output and USB
Power supply	9V DC, center-negative
Current consumption	Less than 100 mA
Dimensions	94 × 51 × 53 mm
Weight	175 grams

Merk	NUX
Serie	NSS-4 Pulse
Afmetingen	94 x 51 x 53 mm
Gewicht	175 grams
Land van herkomst	China
Artikelnummer	NSS-4
Barcode (EAN)	8719147517297
